Features:
* Auto-control, auto-detection, auto-diagnosis and auto-alarm.
* Auto-temperature control and high temperature control precision.
* Auto-time control and auto-timing shutdown.
* Auto-display, auto-latching, auto-reset and auto-cyclic test.
* Automatic control of friability and high control precision for cylinder rotation speed and number of turns.
* Hardness high-precision pressure sensor, digital display of hardness value.
* Continuous measurement of tablet hardness value, manual tablet feeding, motor control and automatic compression.
* Two-path disintegration operates at the same time, automatic timing shutdown.
* Imported SUS316 stainless steel is adopted for dissolution rotation baskets and paddle rods, etc.
Technical Parameters:
Model | TFUT-3 |
Temperature Range | (20~40℃)±0.3℃ |
Speed Range | (20~200rpm)±2rpm |
AutomaticTime Range | (1~900min)±0.5min |
Stations of Dissolution | 3 |
Paddle Radial Run-out | ±0.5mm |
Basket Radial Run-out | ±1.0mm |
Basket Assemblies | 2 |
Nacelle Back and Forth Frequency | (30~32)times/min |
Nacelle Back and Forth Range | (55±2)mm |
Drum | 1 |
Drum’s Inner Size | Φ286*H39mm |
Tablet Fall Height | 156mm |
Rotating Speed | (25±1)times/min |
RotatingCount | (100±1)turns |
Hardness Range | (25~199)±1N |
Diameter Range | (3~40)mm |
Power Supply | AC110/220V±10%, 50/60Hz |
Dimensions(L*W*H)mm | 520*380*470 |
Packing Size(L*W*H)mm | 700*440*680 |
Gross Weight(Kg) | 45 |
